2U Twin Server

SKU:
6026TT-HDTRF

Description


This is a Supermicro 6026TT-HDIBXRF 2U Twin Server with a 3 Year Warranty.

The 2U Twin is the latest addition to Supermicro's family of twin servers. 2U Twin introduces an innovative architecture where the devices are hot-swappable to facilitate ease of maintenance, reduce/eliminate down time, while saving power and space by sharing the same chassis and power supplies. The new 2U Twin server features two compute nodes with x16 non-blocking native Gen2 PCI-Express connectivity to the processor and redundant 1400-watt Gold Level (93%+ efficiency) power supplies for maximum availability. Each compute node supports six hot-swap 3.5" SATA drives to deliver unprecedented I/O performance, and an industry leading 6 hot-swap HDD per 1U.


These highly parallel systems are optimized for a wide range of graphics and computationally intensive applications in fields like HPC, Medical imaging, Oil and gas exploration, Quantum chemistry, Financial simulation, Genomics, and Astrophysics.


For more information: Please e-mail us at sales@vectordata.com. We can customize servers to your needs.


Specifications:


Features

Product SKUs

  • SYS-6026TT-HDIBXRF: SuperServer 6026TT-HDIBXRF (Black
Motherboard
  • 2x Super X8DTT-HIBXF+
CPU (per node):
  • Dual 1366-pin LGA Sockets
  • Supports up to two Intel 64-bit Xeon processor(s): Quad-Core Intel Xeon Processor 5500 sequence (Nehalem-EP processor)
  • QPI: up to 6.4 GT/s
System Cooling (per node)
  • 4x Cooling Fans
Drives and Back Plane(per node)
  • Drive Bays: 6x 3.5" SATA Hot-swap drive bays
  • Backplane: 2U Hard drive Backplane
Memory (per node)

Memory Capacity

  • 12x 240-pin DIMM sockets
  • Supports up to 96 GB 1333 / 1066 / 800MHz DDR3 ECC Registered memory
  • Supports up to 24 GB 1333 / 1066 / 800MHz DDR3 ECC Unbuffered memory
  • Memory Mirroring supported
Memory Type
  • 1333 / 1066 / 800MHz ECC Registered / ECC Unbuffered DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes
  • 1GB, 2GB, 4GB, 8GB
Memory Voltage
  • 1.5 V
Error Detection
  • Corrects single-bit errors
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
  • Supports Intel? x4 and x8 Single Device Data Correction (SDDC)
On-Board Devices (per node)

Chipset

  • Intel 5520 (Tylersburg) chipset
  • ICH10R Serial ATA
    • Intel ICH10R SATA 3.0Gbps Controller
    • RAID 0, 1, 5, 10 support IPMI
      • Support for Intelligent Platform Management Interface v.2.0
      • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
      • Winbond WPCM450 BMC Network Controllers
        • Dual Intel 82574L Gigabit Ethernet Controller
        • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
        • Intel I/OAT 3 support for fast, scaleable, and reliable networking
        • VMDq support for better performance of virtualization
        • 1x Realtek RTL8201N PHY (dedicated IPMI) Graphics
          • Matrox G200eW Super I/O
            • Winbond W83527HG chip Clock Generator
              • 932S421 chip
                Input / Output (per node)

                Serial ATA

                • Six Serial ATA ports
                • Six SATA hard drives supported
                LAN
                • 2x RJ45 LAN ports
                • 1x RJ45 Dedicated IPMI LAN port
                USB
                • 2 rear + 1 header (2 Ports)
                • 4 total USB ports, 2.0 Compliant / 1.1 Compliant
                VGA
                • 1x VGA port
                Serial Port
                • 1 Fast UART 16550 serial port
                Chassis

                Form Factor

                • 2U Rackmount
                Model
                • CSE-827HD-R1400B
                Dimensions

                Height

                • 3.5" (89mm)
                Width
                • 17.2" (437mm)
                Depth
                • 28.5" (724mm)
                Gross Weight
                • 85 lbs (38.6kg)
                Available Colors
                • Black
                System BIOS (per node)

                BIOS Type

                • 32Mb SPI Flash EEPROM with AMI BIO
                BIOS Features
                • Plug and Play (PnP)
                • PCI 2.2
                • ACPI up to 3.0
                • USB Keyboard Support
                Expansion Slots (per Node)

                PCI-Express

                • 2 (x8) PCI-E (FH/HL) w/ riser card (in x16 slots)
                Front Panel (per Node)

                Buttons

                • Power On/Off button
                • UID button
                LEDs
                • Power LED (on power button)
                • UID LED (on UID button)
                • Network activity LED
                • System Overheat LED / Fan fail LED / Power Fail/ LED
                1400W high-efficiency power supply with PMBus

                AC Input

                • 1200W: 100 - 140V, 50 - 60Hz, 10.5 - 14.7 Amp
                • 1400W: 180 - 240V, 50 - 60Hz, 7.2 - 9.5 Amp
                DC Output +5V standby
                • 4 Amp
                DC Output +12V
                • 100 Amp @ 100-140V
                • 116 Amp @ 180-240V
                Certification
                • 80 PLUS Gold Certified
                PC Health Monitoring

                CPU

                • Monitors for CPU Cores,+1.5V, +3.3V, +5V, +12V, +5 Stdby, +3.3 Stdby, VBAT, Memory Voltages.
                • CPU Core 6-Phase-switching voltage regulator
                FAN
                • Total of four 4-pin PWM fans
                • 4x fans with tachometer monitoring
                • Status monitor for speed control
                • Status monitor for on/off control
                • Low noise fan speed control
                Temperature
                • Monitoring for CPU and chassis environment
                • CPU thermal trip support
                • Thermal Control for 4x Fan Connectors
                • PSU I2C temperature sensing logic
                • Thermal Monitor 2 (TM2) support
                • PECI
                LED
                • Power Fail / Overheat LED
                • Suspend-state Indicator LED
                • UID LED
                Other Features
                • SDDC Support
                Operating Environment / Compliance

                RoHS

                • RoHS Compliant
                Environmental Spec.
                • Operating Temperature: 10C to 35C (50F to 95F)
                • Non-operating Temperature: -40C to 70C (-40F to 158F)
                • Operating Relative Humidity: 8% to 90% (non-condensing)
                • Non-operating Relative Humidity: 5% to 95% (non-condensing)
