Description
AMD 2U Dual Socket Uio Server with 16 Dimms
Manufacturer Part Number: AS-2022G-URF
Abstract
Achieving new levels of computing performance, Supermicro's 2U Opteron 6100 series processor-based servers offer features such as Intelligent Management (IPMI 2.0) with Virtual Media plus KVM-over-LAN and high-efficiency power supplies to help minimize the total cost of ownership. Ideal for database, application, enterprise server, and SQL server.
Product Specifications Compare with other products.
Product Name AMD 2U Dual Socket Uio Server with 16 Dimms
Product Type Barebone System
Controller AMD Serial ATA/300 Integrated RAID Controller supporting 0, 1, 1+0 RAID Level(s)
Dimensions 3.50" Height x 17.20" Width x 25.50" Depth
Graphics Controller Matrox G200 With 2 MB DDR2 SDRAM Integrated
Maximum Memory 256 GB DDR3-1333/PC3-10600 DDR3 SDRAM ECC or non-ECC Quad-channel
256 GB DDR3-1066/PC3-8500 DDR3 SDRAM ECC or non-ECC Quad-channel
256 GB DDR3-800/PC3-6400 DDR3 SDRAM ECC or non-ECC Quad-channel
Network Intel 82576 IEEE 802.3ab Gigabit Ethernet 10/100/1000Mbps Integrated
Ports 3 x RJ-45 Network
1 x 9-pin DB-9 Serial
1 x 15-pin HD-15 VGA
1 x 6-pin mini-DIN (PS/2) Mouse
1 x 6-pin mini-DIN (PS/2) Keyboard
2 x 4-pin Type A USB 2.0 USB Rear
Color Black
Case Style 2U Rack
Chipset AMD SR5670
Expansion Bays 1 x 5.25" Slimline External Removable Media Bay Total
8 x 3.5" Drive Bay Total Hot-swappable
Product Model 2022G-URF
Optical Drive DVD-Reader ( - )DVD-ROM
Processor Interface Socket G34
Processor Support AMD Opteron (Eight-core)
AMD Opteron (Twelve-core)
Product Line A+ Server
Expansion Slots 1 x Universal I/O Total
3 x PCI Express x8 Total
Input Voltage 100 V AC to 240 V AC
Power Supply 2 x 720 WRedundant
Fan System 3 x (80x38mm 4-pin PWM Fans)
Memory Slots 240-pin DIMM (16 Total)
Total Processor Support 2
Processor Type Opteron AMD Dual Socket Uio Server AS-2022G-URF
